Description

Specifications

Plate type:
96-well plate or other plates

Light source:
8V/20W Halogen lamp

Filters:
405nm,450nm,492nm,630nm
Optional conf. 1: standard 4 types+600nm+620nm
Optional conf. 2: standard 4 types+546nm+600nm
Optional conf. 3: standard 4 types+546nm+620nm
Optional conf. 4: 412nm only

Resolution:
0.001 Abs(Displayed),0.0001Abs(Calculated)

Reading speed:
5 seconds single-wavelength (96 wells)

Reading channel: 8 channels
Calculation Method:
Cut-off,ABS,1 point,Linear Reg,
Semi-log poly, Poly-reg,Spline

Shaking:
high, middle, low speed selectable

Display:
Large touch screen LCD

Memory:
up to 10000 test results

Printer:
Built-in printer or external printer

Interface:
Serial port(RS-232), parallel port(for external
printer)

Dimensions:
460mm(L)×320mm(W)×210mm(H)

Weight:
8kg
